0470R74BN Continental Engine - NEW O-470-R74

Engine Model: 0470R74BN (Factory New)

Engine Configuration

• Model: O-470-R
• Six-Cylinder, Horizontally Opposed
• Air-Cooled, Direct Drive
• Rated at 230 HP @ 2600 RPM
• Carbureted Induction System

Specification Details

• Displacement: 471 cubic inches
• Bore x Stroke: 5.00 in. x 4.00 in.
• Compression Ratio: 8.6:1
• Fuel: 100/100LL Aviation Gasoline
• Weight: Approximately 410 lbs (dry)

Compatible Parts and Accessories

• Magnetos: TCM S6LN-21 (Dual Impulse)
• Starter: TCM 646275A or Equivalent
• Alternator: 12V 60A
• Carburetor: MA-4-5
• Ignition Harness: Shielded 5mm Type

Continental Warranty

All Continental factory engines include industry-leading warranty protection. Factory New engines are covered by a 24-month warranty from the date of shipment. This warranty covers defects in materials and workmanship under normal use and operation. Warranty service and support are available through all authorized Continental Aerospace Technologies service centers.

Sold By

• Air Power, Inc. — Your trusted Continental factory-authorized distributor.
• Phone: 800-247-7693
• Email: sales@airpowerinc.com
• Free shipping within the Continental U.S.

All Continental engines are precision-built to factory specifications. The Air Power team will assist you in matching the correct configuration to your aircraft and mission profile.
